Toshiba H1 Series - Manual (Page 114)

TMP92CZ26A
92CZ26A-111
Table 3.7.1 Port Functions (2/3)
Port Name Pin Name
Number of
Pins
I/O R I/O Setting
Pin Name for built-in
function
PJ0 1 Output
−
(Fixed) SDRAS , SRLLB
PJ1 1 Output
−
(Fixed) SDCAS , SRLUB
PJ2 1 Output
−
(Fixed) SDWE , SRWR
PJ3 1 Output
−
(Fixed) SDLLDQM
PJ4 1 Output − (Fixed) SDLUDQM
PJ5 1 I/O − bit NDALE
PJ6 1 I/O − bit NDCLE
Port J
PJ7 1 Output
−
(Fixed) SDCKE
PK0 1 Output
−
(Fixed) LCP0
PK1 1 Output
−
(Fixed) LLOAD
PK2 1 Output − (Fixed) LFR
PK3 1 Output − (Fixed) LVSYNC
PK4 1 Output − (Fixed) LHSYNC
PK5 1 Output
−
(Fixed) LGOE0
PK6 1 Output
−
(Fixed) LGOE1
Port K
PK7 1 Output
−
(Fixed) LGOE2
Port L PL0 to PL7 8 Output
−
(Fixed) LD0 to LD7
PM1 1 Output − (Fixed) MLDALM, TA1OUT
PM2 1 Output
−
(Fixed) ALARM ,MLDALM
Port M
PM7 1 Output − (Fixed) PWE
Port N PN0 to PN7 8 I/O − bit KO0 to KO7
PP1 1 I/O
−
bit TA3OUT
PP2 1 I/O
−
bit TA5OUT
PP3 1 I/O
−
bit INT5, TA7OUT
PP4 1 I/O
−
bit INT6, TB0IN0
PP5 1 I/O − bit INT7, TB1IN0
PP6 1 Output − (Fixed) TB0OUT0
Port P
PP7 1 Output
−
(Fixed) TB1OUT0
PR0 1 I/O
−
bit SPDI
PR1 1 I/O − bit SPDO
PR2 1 I/O − bit SPCS
Port R
PR3 1 I/O − bit SPCLK
Port T PT0 to PT7 8 I/O
−
bit LD8 to LD15
PU0 to PU4
,PU6
6 I/O − bit LD16 to LD20 , LD22
PU5 1 I/O − bit LD21
Port U
PU7 1 I/O − bit LD23, EO_TRGOUT
PV0 1 I/O
−
bit SCLK0
PV1 1 I/O − bit −
PV2 1 I/O − bit −
PV3 1 Output − (Fixed) −
PV4 1 Output
−
(Fixed)
−
PV6 1 I/O
−
bit SDA
Port V
PV7 1 I/O
−
bit SCL
Port W PW0 to PW7 8 I/O
−
bit
−
PX4 1 Output − bit CLKOUT, LDIV
PX5 1 I/O − bit X1USB
Port X
PX7 1 I/O − bit −
