TMP92CZ26A
92CZ26A-112
Table 3.7.1 Port Functions (3/3)
Port Name Pin Name
Number of
Pins
I/O R I/O Setting
Pin Name for built-in
function
PZ0 1 I/O
−
bit EI_PODDATA
PZ1 1 I/O − bit EI_SYNCLK
PZ2 1 I/O
−
bit EI_PODREQ
PZ3 1 I/O − bit EI_REFCLK
PZ4 1 I/O
−
bit EI_TRGIN
PZ5 1 I/O − bit EI_COMRESET
PZ6 1 I/O
− bit EO_MCUDATA
Port Z
PZ7 1 I/O
−
bit EO_MCUREQ
