TMP92CZ26A
92CZ26A-697
(4) TSI
Symbol Name Address 7 6 5 4 3 2 1 0
TSI7 INGE PTST TWIEN PYEN PXEN MYEN MXEN
R/W R/W R R/W R/W R/W R/W R/W
0 0 0 0 0 0 0 0
TSICR0
TSI
control
register0
01F0H
0: Disable
1: Enable
Input gate
control of
Port
96,97
0: Enable
1: Disable
Detection
condition
0: no
touch
1: touch
INT4
interrupt
control
0: Disable
1: Enable
SPY
0 : OFF
1 : ON
SPX
0 : OFF
1 : ON
SMY
0 : OFF
1 : ON
SMX
0 : OFF
1 : ON
DBC7 DB1024 DB256 DB64 DB8 DB4 DB2 DB1
R/W
0 0 0 0 0 0 0 0
1024 256 64 8 4 2 1
TSICR1
TSI
control
register1
01F1H
0: Disable
1: Enable
De-bounce time is set by “(N*64-16) / f
SYS
”-formula.
“N” is sum of number which is set to “1” in bit6 to bit 0.
