TMRA45 RUN Register
7 6 5 4 3 2 1 0
Bit symbol TA4RDE I2TA45 TA45PRUN TA5RUN TA4RUN
Read/Write R/W R/W
After Reset 0 0 0 0 0
TMRA45
prescaler Up counter
(UC5) Up counter
(UC4) Function
Double
buffer
0: Disable
1: Enable
In IDLE2
mode
0: Stop
1: Operate
0: Stop and clear
1: Run (Count up)
Note: The values of bits 4 to 6 of TA45RUN are “1” when read.
TMRA67RUN Register
7 6 5 4 3 2 1 0
Bit symbol TA6RDE I2TA67 TA67PRUN TA7RUN TA6RUN
Read/Write R/W R/W
After Reset 0 0 0 0 0
TMRA67
prescaler Up counter
(UC7) Up counter
(UC6) Function Double
buffer
0: Disable
1: Enable
In IDLE2
mode
0: Stop
1: Operate
0: Stop and clear
1: Run (Count up)
Note: The values of bits 4 to 6 of TA67RUN are “1” when read.
Figure 3.12.7 Register for TMRA (2)
TA45RUN
(1110H)
TA4REG double buffer control
0 Disable
1 Enable
Count control
0 Stop and clear
1 Run (Count up)
TA67RUN
(1118H)
TA6REG double buffer control
0 Disable
1 enable
Count control
0 Stop and clear
1 Run (Count up)
