TMP92CZ26A
92CZ26A-71
Default
Priority
Type
Interrupt Source and Source of
Micro DMA Request
Vector
Value
Address Refer
to Vector
Micro DMA
/HDMA Start
Vector
51 INTADHP: AD most priority conversion end 00C8H FFFFC8H 32H
52 INTAD: AD conversion end 00CCH FFFFCCH 33H
53 INTTC0/INTDMA0: Micro DMA0 /HDMA0 end 00D0H FFFFD0H 34H
54 INTTC1/INTDMA1: Micro DMA1 /HDMA1 end 00D4H FFFFD4H 35H
55 INTTC2/INTDMA2: Micro DMA2 /HDMA2 end 00D8H FFFFD8H 36H
56 INTTC3/INTDMA3: Micro DMA3 /HDMA3 end 00DCH FFFFDCH 37H
57 INTTC4/INTDMA4: Micro DMA4 /HDMA4 end 00E0H FFFFE0H 38H
58 INTTC5/INTDMA5: Micro DMA5 /HDMA5 end 00E4H FFFFE4H 39H
59 INTTC6 : Micro DMA6 end 00E8H FFFFE8H 3AH
60 INTTC7 : Micro DMA7 end 00ECH FFFFECH 3BH
−
to
−
Maskable
(Reserved)
00F0H
:
00FCH FFFFF0H
:
FFFFFCH
−
to
−
Note 1: When standing-up micro DMA/HDMA , set at edge detect mode.
Note 2 : Micro DMA default priority.
Micro DMA stands up prior to other maskable interrupt.
