Example: To output 2ms one-shot pulse with 3ms delay to the external trigger pulse to
TB0IN0pin
*Clock state
System clock : f
SYS
Prescaler clock : f
SYS
/4
Main setting
Free-running
Count with
φT1
TB0MOD ← X X 1 0 1 0 0 1
Load to TB0CP0H/L at the rising edge of TB0IN0
TB0FFCR
← X X 0 0 0
0 1 0
Clear TB0FF0 to “0”
Disable TB0FF0 inversion
PPFC ← – 1 – – – – – X
Select PP6 as TB0OUT0 pin (port setting)
INTE56 ← X 1 0 0 X – – – Enable INT6
INTETB0 ← X 0 0 0 X 0 0 0 Disable INTTB00, INTTB01
TB0RUN
← – 0 X X –
1 X 1 Start TMRB0
Setting in INT6 routine
TB0RG0
← TB0CP0 + 3ms/φT1
TB0RG1 ← TB0RG0 + 2ms/φT1
TB0FFCR ← X X – – 1 1 – –
Enable TB0FF0 inversion when the up counter value
matches TB0RG0H/L or TB0RG1H/L
INTETB0 ← X 1 0 0 X 0 0 0 Enable INTTB01
Setting in INTTB01 routine
TB0FFCR
← X X – – 0
0 – –
Disable TB0FF0 inversion when the up counter value
matches TB0RG0H/L or TB0RG1H/L
INTETB0
← X 0 0 0 X
0 0 0 Disable INTTB01
X: Don't care,
−: No change
When delay time is unnecessary, invert timer flip-flop TB0FF0 when the up counter
value is loaded into capture register (TB0CP0H/L), and set the TB0CP0H/L value (c)
plus the one –shot pulse width (p) to TB0RG1H/L when the interrupt INT6 occurs.
The TB0FF0 inversion should be enabled when the up counter (UC10) value matched
TB0RG1H/L, and disabled when generating the interrupt INTTB01.
