TMP92CZ26A
92CZ26A-1
CMOS 32-Bit Micro controllers
TMP92CZ26AXBG
1.
Outline and Features
TMP92CZ26A is high-speed advanced 32-bit micro-controller developed for controlling equipment which
processes mass data.
TMP92CZ26AXBG is housed in a 228-pin BGA package.
(1) CPU : 32-bit CPU(High-speed 900/H1 CPU)
• Compatible with TLCS-900/L1 instruction code
• 16Mbytes of linear address space
• General-purpose register and register banks
• Micro DMA : 8channels
(62.5ns/4 bytes at f
SYS
= 80MHz, best case)
(2) Minimum instruction execution time : 12.5ns ( at f
SYS
= 80MHz)
(3) Internal RAM: 288K-byte (can be used for program, data and display memory)
Internal ROM: 8 K-byte(memory for Boot only)
It enables that load user program from USB, UART
to Internal RAM.
