TMP92CZ26A
92CZ26A-642
Symbol Parameter Min Typ. Max Unit Condition
VIH0
Input High Voltage for
D0 to D7
P10 to P17 (D8 to 15), P60 to P67
P71 to P76, P90
PC4 to PC7, PF0 to PF5
PG0 to PG5, PJ5 to PJ6
PN0 to PN7, PP1 to PP2
PR0 to PR3, PT0 to PT7
PU0 to PU7, PX5, PX7
0.7 ×
DVCC3A
– DVCC3A + 0.3 3.0 DVCC3A 3.6
VIH1
Input High Voltage for
PV0 to PV2, PV6 to PV7, PW0 to PW7
0.7 ×
DVCC3B
– DVCC3B + 0.3 3.0 DVCC3B 3.6
VIH2
Input High Voltage for
P91 to P92, P96 to P97, PA0 to PA7
PC0 to PC3, PP3 to PP5, PZ0 to PZ7,
RESET
0.75
DVCC3A
– DVCC3A + 0.3 3.0 DVCC3A 3.6
VIH3
Input High Voltage for
AM0 to AM1 , DBGE
0.9
DVCC3A
– DVCC3A + 0.3 3.0 DVCC3A 3.6
VIH4
Input High Voltage for
X1
0.9
×DVCC1C –
DVCC1C + 0.3 1.4 DVCC1C 1.6
VIH5
Input High Voltage for
XT1
0.85
×
DVCC3A
– DVCC3A + 0.3
V
3.0 DVCC3A 3.6
