TMP92CZ26A
92CZ26A-604
AD Conversion Result Compare Criterion Register 0 Low
7 6 5 4 3 2 1 0
bit
Symbol
ADR21
ADR20
Read/Write R/W
After
reset
0
0
Function
Store Lower 2 bits of an
AD conversion result
compare criterion
AD Conversion Result Compare Criterion Register 0 High
7 6 5 4 3 2 1 0
bit Symbol
ADR29
ADR28
ADR27
ADR26 ADR25 ADR24 ADR23 ADR22
Read/Write R/W
After
reset
0 0 0 0 0 0 0 0
Function
Store Upper 8 bits of an AD conversion result compare criterion
AD Conversion Result Compare Criterion Register 1 Low
7 6 5 4 3 2 1 0
bit
Symbol
ADR21
ADR20
Read/Write R/W
After
reset
0
0
Function
Store Lower 2 bits of an
AD conversion result
compare criterion
AD Conversion Result Compare Criterion Register 1 High
7 6 5 4 3 2 1 0
bit Symbol
ADR29
ADR28
ADR27
ADR26 ADR25 ADR24 ADR23 ADR22
Read/Write R/W
After
reset
0 0 0 0 0 0 0 0
Function
Store Upper 8 bits of an AD conversion result compare criterion
Note: Disable the AD monitor function (ADMOD4
= “0”) before attempting to set or modify
the value of these registers.
Figure 3.23.10 AD Conversion Registers
ADCM0REGL
(12B4H)
ADCM0REGH
(12B5H)
ADCM1REGL
(12B6H)
ADCM1REGH
(12B7H)
