TMP92CZ26A
92CZ26A-636
Port U Register
7 6 5 4 3 2 1 0
Bit Symbol PU7 PU6 PU5 PU4 PU3 PU2 PU1 PU0
Read/Write R/W
After reset External pin data (Output latch is reset to “0”.)
Port U Control Register
7 6 5 4 3 2 1 0
Bit Symbol PU7C PU6C PU5C PU4C PU3C PU2C PU1C PU0C
Read/Write W
After reset 0 0 0 0 0 0 0 0
Function 0: Input 1: Output
Port U Function Register
7 6 5 4 3 2 1 0
Bit Symbol PU7F PU6F PU5F PU4F PU3F PU2F PU1F PU0F
Read/Write W
After reset 0 0 0 0 0 0 0 0
Function 0: Port 1: Data bus for LCDC (LD23 to LD16)
Note: When LD23 to LD16 are used, set to “1”.
Port U Drive Register
7 6 5 4 3 2 1 0
Bit Symbol PU7D PU6D PU5D PU4D PU3D PU2D PU1D PU0D
Read/Write R/W
After reset 1 1 1 1 1 1 1 1
Function Input/output buffer drive register for standby mode
Note: Although it is possible to write to shaded bits, writing to these bits has no effect (the DSU communication function is
given a higher priority).
PUFC
(00A7H)
PUCR
(00A6H)
PUDR
(009CH)
PU
(00A4H)
