TMP92CZ26A
92CZ26A-668
[2] INTC
Address Name Address Name Address Name Address Name
00D0H INTE12 00E0H INTESBIADM 00F0H INTE0 0100H DMA0V
1H INTE34 1H INTESPI 1H INTETC01
/INTEDMA01
1H DMA1V
2H INTE56 2H Reserved 2H INTETC23
/INTEDMA23
2H DMA2V
3H INTE7 3H INTEUSB 3H INTETC45
/INTEDMA45
3H DMA3V
4H INTETA01 4H Reserved 4H INTETC67 4H DMA4V
5H INTETA23 5H INTEALM 5H SIMC 5H DMA5V
6H INTETA45 6H Reserved 6H IIMC0 6H DMA6V
7H INTETA67 7H 7H INTWDT 7H DMA7V
8H INTETB0 8H INTERTC 8H INTCLR 8H DMAB
9H INTETB1 9H INTEKEY 9H 9H DMAR
AH AH INTELCD AH IIMC1 AH DMASEL
BH INTES0 BH INTEI2S01 BH BH
CH CH INTENDFC CH CH
DH DH Reserved DH DH
EH EH INTEP0 EH EH
FH FH INTEAD FH Reserved FH
[3] MEMC [4] TSI
Address Name Address Name Address Name Address Name
0140H B0CSL 0150H 0160H 01F0H TSICR0
1H B0CSH 1H 1H 1H TSICR1
2H MAMR0 2H 2H 2H Reserved
3H MSAR0 3H 3H 3H
4H B1CSL 4H 4H 4H
5H B1CSH 5H 5H 5H
6H MAMR1 6H 6H PMEMCR 6H
7H MSAR1 7H 7H 7H
8H B2CSL 8H BEXCSL 8H CSTMGCR 8H
9H B2CSH 9H BEXCSH 9H WRTMGCR 9H
AH MAMR2 AH AH RDTMGCR0 AH
BH MSAR2 BH BH RDTMGCR1 BH
CH B3CSL CH CH BROMCR CH
DH B3CSH DH DH RAMCR DH
EH MAMR3 EH EH EH
FH MSAR3 FH FH FH
Note: Do not access no allocated name address.
