TMP92CZ26A
92CZ26A-675
[13] CGEAR, PLL [14] 8-bit timer
Address Name Address Name Address Name
10E0H SYSCR0 1100H TA01RUN 1110H TA45RUN
1H SYSCR1 1H 1H
2H SYSCR2 2H TA0REG 2H TA4REG
3H EMCCR0 3H TA1REG 3H TA5REG
4H EMCCR1 4H TA01MOD 4H TA45MOD
5H EMCCR2 5H TA1FFCR 5H TA5FFCR
6H Reserved 6H 6H
7H 7H 7H
8H PLLCR0 8H TA23RUN 8H TA67RUN
9H PLLCR1 9H 9H
AH AH TA2REG AH TA6REG
BH BH TA3REG BH TA7REG
CH CH TA23MOD CH TA67MOD
DH DH TA3FFCR DH TA7FFCR
EH EH EH
FH FH FH
[15] 16-bit timer [16] SIO [17] SBI
Address Name Address Name Address Name Address Name
1180H TB0RUN 1190H TB1RUN 1200H SC0BUF 1240H SBI0CR1
1H 1H 1H SC0CR 1H SBI0DBR
2H TB0MOD 2H TB1MOD 2H SC0MOD0 2H I2C0AR
3H TB0FFCR 3H TB1FFCR 3H BR0CR 3H SBI0CR2/SBI0SR
4H 4H 4H BR0ADD 4H SBI0BR0
5H 5H 5H SC0MOD1 5H
6H 6H 6H 6H
7H 7H 7H SIRCR 7H SBI0CR0
8H TB0RG0L 8H TB1RG0L 8H 8H
9H TB0RG0H 9H TB1RG0H 9H 9H
AH TB0RG1L AH TB1RG1L AH AH
BH TB0RG1H BH TB1RG1H BH BH
CH TB0CP0L CH TB1CP0L CH CH
DH TB0CP0H DH TB1CP0H DH DH
EH TB0CP1L EH TB1CP1L EH EH
FH TB0CP1H FH TB1CP1H FH FH
Note: Do not access no allocated name address.
