TMP92CZ26A
92CZ26A-516
LCD Sub Area HOT Point Register (X-dir)
7 6 5 4 3 2 1 0
bit Symbol SAHX7 SAHX6 SAHX5 SAHX4 SAHX3 SAHX2 SAHX1 SAHX0
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
After reset 0 0 0 0 0 0 0 0
Function LCD sub area HOT point (7-0)
7 6 5 4 3 2 1 0
bit Symbol SAHX9 SAHX8
Read/Write R/W R/W
After reset 0 0
Function
LCD sub area HOT
point (9-8)
LCD Sub Area HOT Point Register (Y-dir)
7 6 5 4 3 2 1 0
bit Symbol SAHY7 SAHY6 SAHY5 SAHY4 SAHY3 SAHY2 SAHY1 SAHY0
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
After reset 0 0 0 0 0 0 0 0
Function LCD sub area HOT point (7-0)
7 6 5 4 3 2 1 0
bit Symbol SAHY8
Read/Write R/W
After reset 0
Function
LCD sub
area HOT
point (8)
LCD Sub Area Display Segment Size Register
7 6 5 4 3 2 1 0
bit Symbol SAS7 SAS6 SAS5 SAS4 SAS3 SAS2 SAS1 SAS0
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
After reset 0 0 0 0 0 0 0 0
Function LCD sub area segment size (7-0)
7 6 5 4 3 2 1 0
bit Symbol SAS9 SAS8
Read/Write R/W R/W
After reset 0 0
Function
LCD sub area segment
size (9-8)
LCD Sub Area Display Common Size Register
7 6 5 4 3 2 1 0
bit Symbol SAC7 SAC6 SAC5 SAC4 SAC3 SAC2 SAC1 SAC0
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
After reset 0 0 0 0 0 0 0 0
Function LCD sub area common size (7-0)
7 6 5 4 3 2 1 0
bit Symbol SAC8
Read/Write R/W
After reset 0
Function LCD sub area common size (8)
LSAHX
(02A8H)
(02A9H)
LSASS
(02ACH)
(02ADH)
(02AFH)
LSACS
(02AEH)
LSAHY
(02AAH)
(02ABH)
