TMP92CZ26A
92CZ26A-715
(10) MMU (4/8)
Symbol Name Address 7 6 5 4 3 2 1 0
X7 X6 X5 X4 X3 X2 X1 X0
R/W
0 0 0 0 0 0 0 0
LOCALWX
LOCALX
register
for
write
0898H
Set BANK number for LOCAL-X (“0” is disabled because of overlapped with Common-area.)
LXE X8
R/W R/W
0 0
LOCALWX
LOCALX
register
for
write
0899H LOCALX
BANK
0:disable
1:enable
Set BANK number for LOCAL-X
X8-X0 setting and CS
000000000
∼011111111 CSXA
100000000
∼111111111 CSXB
Y5 Y4 Y3 Y2 Y1 Y0
R/W
0 0 0 0 0 0 LOCALWY
LOCALY
register
for
write
089AH
Set BANK number for LOCAL-Y
(“3” is disabled because of overlapped with Common-area.)
LYE
R/W
0
LOCALWY
LOCALY
register
for
write
089BH
LOCALY
BANK
0:disable
1:enable
Z7 Z6 Z5 Z4 Z3 Z2 Z1 Z0
R/W
0 0 0 0 0 0 0 0
LOCALWZ
LOCALZ
register
for
write
089CH
Set BANK number for LOCAL-Z (“3” is disabled because of overlapped with Common-area.)
LZE Z8
R/W R/W
0 0
LOCALWZ
LOCALZ
register
for
write
089DH LOCALZ
BANK
0:disable
1:enable
Set BANK number for LOCAL-Z
Z8-Z0 setting and CS
000000000
∼001111111 CSZA 100000000∼101111111 CSZC
010000000 ∼011111111 CSZB 110000000∼111111111 CSZD
