TMP92CZ26A
92CZ26A-279
TMRA67 Mode Register
7 6 5 4 3 2 1 0
Bit symbol TA67M1 TA67M0 PWM61 PWM60 TA7CLK1 TA7CLK0 TA6CLK1 TA6CLK0
Read/Write R/W
After reset 0 0 0 0 0 0 0 0
Function Operation mode
00: 8-bit timer mode
01: 16-bit timer mode
10: 8-bit PPG mode
11: 8-bit PWM mode
PWM cycle
00: Reserved
01: 2 6
10: 2 7
11: 2 8
TMRA7 clock for TMRA7
00: TA6TRG
01:
φT1
10: φT16
11:
φT256
TMRA6 clock for TMRA6
00: low-frequency clock
01:
φT1
10: φT4
11:
φT16
00 low-frequency clock(fs)
01
φT1
10
φT4
11
φT16
TA67MOD ≠01 TA67MOD =01
00 Comparator output
from TMRA6
01
φT1
10
φT16
11 φT256
Overflow output from TMRA6
(16-bit timer mode)
00 Reserved
01 2 6 × Clock source
10 2 7 × Clock source
11 2 8 × Clock source
00 8 timer
× 2ch
01 16-bit timer
10 8-bit PPG
11 8-bit PWM (TMRA6),
8-bit timer (TMRA7)
Figure 3.12.11 Register for TMRA (7)
TA67MOD
(111CH)
PWM cycle selection
TMRA1 input clock
TMRA67 operation mode selection
TMRA6 input clock
