TMP92CZ26A
92CZ26A-222
SDRAM Command Register
7 6 5 4 3 2 1 0
Bit symbol SCMM2 SCMM1 SCMM0
Read/Write R/W
After reset 0 0 0
Function
Command issue (Note 1) (Note 2)
000: Don’t care
001: Initialization sequence
a. Precharge All command
b. Eight Auto Refresh commands
c. Mode Register Set command
010: Precharge All command
100: Reserved
101: Self Refresh Entry command
110: Self Refresh Exit command
Others: Reserved
Note 1: is automatically cleared to “000” after the specified command is issued. Before writing the next
command, make sure that is “000”. In the case of the Self Refresh Entry command, however,
is not cleared to “000” by execution of this command. Thus, this register can be used as a flag for
checking whether or not Self Refresh is being performed.
Note 2: The Self Refresh Exit command can only be specified while Self Refresh is being performed.
SDRAM HDMA Burst Length Select Register
7 6 5 4 3 2 1 0
Bit symbol SDBL5 SDBL4 SDBLS SDBL2 SDBL1 SDBL0
Read/Write R/W
After reset 0 0 0 0 0 0
For HDMA5 For HDMA4 For HDMA3 For HDMA2 For HDMA1 For HDMA0
Function
HDMA burst length
0: 1 Word read / Single write
1: Full page read / Burst write
Figure 3.10.1 Control Registers
SDCMM
(0253H)
SDBLS
(0254H)
