(3) Hour column register (for PAGE0/1)
1. In case of 24-hour clock mode (MONTHR= “1”)
7 6 5 4 3 2 1 0
Bit symbol HO5 HO4 HO3 HO2 HO1 HO0 HOURR
(1322H)
Read/Write R/W
After reset Undefined
Function "0" is read. 20 hour
column
10 hour
column
8 hour
column
4 hour
column
2 hour
column
1 hour
column
0 0 0 0 0 0 0 o’clock
0 0 0 0 0 1 1 o’clock
0 0 0 0 1 0 2 o’clock
:
0 0 1 0 0 0 8 o’clock
0 0 1 0 0 1 9 o’clock
0 1 0 0 0 0 10 o’clock
:
0 1 1 0 0 1 19 o’clock
1 0 0 0 0 0 20 o’clock
:
1 0 0 0 1 1 23
Note: Do not set the data other than showing above.
2. In case of 24-hour clock mode (MONTHR= “0”)
7 6 5 4 3 2 1 0
Bit symbol HO5 HO4 HO3 HO2 HO1 HO0 HOURR
(1322H)
Read/Write R/W
After reset Undefined
Function "0" is read.
PM/AM
10 hour
column
8 hour
column
4 hour
column
2 hour
column
1 hour
column
0 0 0 0 0 0
0 o’clock
(AM)
0 0 0 0 0 1 1 o’clock
0 0 0 0 1 0 2 o’clock
:
0 0 1 0 0 1 9 o’clock
0 1 0 0 0 0 10 o’clock
0 1 0 0 0 1 11 o’clock
1 0 0 0 0 0 0 o’clock
(PM)
1 0 0 0 0 1 1 o’clock
Note: Do not set the data other than showing above.
