TMP92CZ26A
92CZ26A-384
3.16.3.3 bmRequestType Register
This register shows the bmRequestType field of device request.
7 6 5 4 3 2 1 0
bit Symbol DIRECTION REQ_TYPE1 REQ_TYPE0 RECIPIENT4 RECIPIENT3 RECIPIENT2 RECIPIENT1 RECIPIENT0
Read/Write R R R R R R R R
After reset 0 0 0 0 0 0 0 0
DIRECTION (Bit7) 0: from host to device
1: from device to host
REQ_TYPE [1:0] (Bit6 to bit5) 00: Standard
01: Class
10: Vendor
11: (Reserved)
RECEIPIENT [4:0] (Bit4 to bit0) 00000: Device
00001: Interface
00010: Endpoint
00011: etc.
Others: (Reserved)
3.16.3.4 bRequest Register
This register shows the bRequest field of device request.
7 6 5 4 3 2 1 0
bit Symbol REQUEST7 REQUEST6 REQUEST5 REQUEST4 REQUEST3 REQUEST2 REQUEST1 REQUEST0
Read/Write R R R R R R R R
After reset 0 0 0 0 0 0 0 0
(Standard) (Printer class)
00000000: GET_STATUS 00000000: GET_DEVICE_ID
00000001: CLEAR_FEATURE 00000001: GET_PORT_STATUS
00000010: Reserved 00000010: SOFT_RESET
00000011: SET_FEATURE
00000100: Reserved
00000101: SET_ADDRESS
00000110: GET_DESCRIPTOR
00000111: SET_DESCRIPTOR
00001000: GET_CONFIGURATION
00001001: SET_CONFIGURATION
00001010: GET_INTERFACE
00001011: SET_INTERFACE
00001100: SYNCH_FRAME
bmRequestType
(07C0H)
bRequest
(07C1H)
