Ifc 1 WAN PPP CSR 81620, CSR2 80D00, vector 93
Ifc 2 WAN V.25bis CSR 81640, CSR2 80E00, vector 92
Config>add v25
Assign address name (1-23) chars []? brown
Assign network dial address (1-30 digits) []? 555-1211
Assign address name (1-23) chars []? gray
Assign network dial address (1-30 digits) []? 555-1212
Config>list v25
Address assigned name Network Address
--------------------- ---------------
brown 555-1211
gray 555-1212
Config>add device dial
Adding device as interface 3
Defaulting Data-link protocol to PPP
Use net 3 command to configure circuit parameters
Config>net 3
Circuit configuration
Circuit config: 3>list all.
Base net = 0
Destination name =
Circuit priority = 8
Outbound calls = allowed
Inbound calls = allowed
Idle timer = 60 sec 1
SelfTest Delay Timer = 150 ms
Circuit config: 3>set net
Base net for this circuit [0]? 2
Circuit config: 3>set idle 0 2
Circuit config: 3>set dest
Assign destination address name []? brown
Circuit config:
3>list all
Base net = 2
Destination name = brown
Circuit priority = 8
Destination address: subaddress = 555-1211
Outbound calls = allowed
Inbound calls = allowed
Idle timer = 0 (fixed circuit)
SelfTest Delay Timer = 150 ms
Circuit config: 3>ex
Config>net 2
V.25bis Data Link Configuration
V25bis Config>list all
V.25bis Configuration
Local Network Address Name = Unassigned
No local addresses configured
Non-Responding addresses:
Retries = 1
Timeout = 0 seconds
Call timeouts:
Command Delay = 0 ms
Connect = 60 seconds
Disconnect = 2 seconds
Cable type = RS-232 DTE
Speed (bps) = 9600
V25bis Config>set local
Local network address name []? gray
V25bis Config>list all
V.25bis Configuration
Local Network Address Name = gray
Local Network Address = 555-1212
