2 The alternate route is interface 4 and is disabled
3 Destination of WAN reroute is NN6
4 Configure WAN reroute primary and alternate
5 Add the APPN port to NN22
6 Link station on APPN port (NN22)
7 Primary port
8 Alternate port
9 Alternate station to NN6
10 Primary station to NN6
11 Destination configuration
12 APPN port on destination; link station will be dynamically created when WAN
reroute occurs.
Configuring WAN Restoral
The following example shows APPN over a primary PPP link. For APPN, no unique
definitions are needed. Both sides of the communication link are enabled for WAN
restoral and are similarly configured.
*************************************************************************
*** Configuration of NN6 with a Wan Restoral link to NN35
*** interface 1 is the primary, interface 8 is the Secondary
*** NN35 must also have Wan Restoral configured for its primary/secondary
*** interfaces
**** Note that for APPN, there are NO unique definitions needed.
*************************************************************************
Circuit configuration
FR Config>li al
Base net = 6
Destination name = 2210-35
Circuit priority = 8
Inbound destination name = 2210-35
Inbound calls = allowed
Idle timer = 0 (fixed circuit)
SelfTest Delay Timer = 150 ms
FR Config>ex
Config>fea wan
WAN Restoral user configuration
WRS Config>li all
WAN Restoral is enabled. 1
Default Stabilization Time: 0 seconds
Default First Stabilization Time: 0 seconds
Secondary
Primary Interface Secondary Interface Enabled
----------------------- ----------------------- --------
1 - WAN PPP 8 - PPP Dial Circuit Yes
[No Primary-Alternate pairs defined ]
WRS Config>ex
Config>p appn
APPN user configuration
APPN config>li al
NODE:
NETWORK ID: STFNET
CONTROL POINT NAME: NN6
XID: 00000
APPN ENABLED: YES
MAX SHARED MEMORY: 4096
MAX CACHED: 4000
DLUR:
DLUR ENABLED: YES
PRIMARY DLUS NAME: NETB.MVSC
APPN
Chapter 1. APPN 59
