* Below is SDLC
************************************************************************
*A20RT
PATH PID=1,
*
DLURNAME=GREEN,
*
DLCADDR=(1,C,SDLCNS),
*
DLCADDR=(2,X,5353),
2
**port name
*
DLCADDR=(3,X,C1)
3a
**station address
************************************************************************
* Below is Frame Relay
************************************************************************
*A20RT
PATH PID=2,
*
DLURNAME=GREEN,
*
DLCADDR=(1,C,FRPVC),
*
DLCADDR=(2,X,4652303033),
2
**port name
*
DLCADDR=(3,X,04),
3
**SAP address
*
DLCADDR=(4,X,0024)
4
**DLCI
************************************************************************
* Below is Frame Relay BAN
************************************************************************
*A20RT
PATH PID=3,
*
DLURNAME=GREEN,
*
DLCADDR=(1,C,FRPVC),
*
DLCADDR=(2,X,4652303033),
2
**port name
*
DLCADDR=(3,X,04),
3
**SAP address
*
DLCADDR=(4,X,0024),
4
**DLCI
*
DLCADDR=(6,X,400000000001)
5
**MAC addr
************************************************************************
* Below is DLSw
************************************************************************
*A20RT
PATH PID=3,
*
DLURNAME=GOLD,
*
DLCADDR=(1,C,TR),
7
*
DLCADDR=(2,X,444C53323534),
2
**port name
*
DLCADDR=(3,X,04),
3
**SAP address
*
DLCADDR=(4,X,400000000001)
6
**MAC address
*
*************************************************************************
** Below is Token Ring
*************************************************************************
*PATHT20 PATH PID=1,
*
DLURNAME=RED,
*
DLCADDR=(1,C,TR),
*
DLCADDR=(2,X,5452303030),
2
**port name
*
DLCADDR=(3,X,04),
3
**SAP address
*
DLCADDR=(4,X,400000011088)
6
**MAC address
*************************************************************************
** Below is Ethernet
*************************************************************************
*PATHE20 PATH PID=1,
*
DLURNAME=PURPLE,
*
DLCADDR=(1,C,ETHERNET),
*
DLCADDR=(2,X,454E303030),
2
**port name
*
DLCADDR=(3,X,20),
3
**SAP address
*
DLCADDR=(4,X,400000011063)
6
**MAC address
************************************************************************
* Below is X25 SVC
************************************************************************
*A20RT
PATH PID=3,
*
DLURNAME=GREEN,
*
DLCADDR=(1,C,X25SVC),
*
DLCADDR=(2,X,583235303033),
2
**port name
*
DLCADDR=(4,X,C3),
8
**Protocol identifier
*
DLCADDR=(21,X,000566666),
9
**Destination DTE address
************************************************************************
* Below is X25 PVC
************************************************************************
*A20RT
PATH PID=3,
*
DLURNAME=GREEN,
*
DLCADDR=(1,C,X25PVC),
*
DLCADDR=(2,X,583235303033),
2
**port name
*
DLCADDR=(3,X,0001)
10
**Logical channel number
************************************************************************
************************************************************************
************************************************************************
* LU statements
************************************************************************
************************************************************************
*PU21LU1 LU
LOCADDR=2
11
APPN
Chapter 1. APPN
11
