Table 32. Configuration Parameter List - TG Characteristics (Connection
Network) (continued)
Parameter Information
Parameter
Effective capacity
Valid Values
2 hexadecimal digits in the range X'00' to X'FF'
Default Value
X'75'
Description
This parameter specifies the effective maximum bit transmission rate for this connection
network TG. Effective capacity specifies the maximum effective rate for both physical
links and logical links.
The effective capacity is encoded as a single-byte representation. The values X'00' and
X'FF' are special cases used to denote minimum and maximum capacities. The range
of the encoding is very large; however, only 256 values in the range may be specified.
Parameter
First user-defined characteristic
Valid Values
0 to 255
Default Value
128
Description
This parameter specifies the first of three additional characteristics that users may
define to describe the TGs in the network. The default value of 128 allows a subset of
TGs to be defined as more or less desirable than the rest without defining values for all
TGs.
Parameter
Second user-defined characteristic
Valid Values
0 to 255
Default Value
128
Description
This parameter specifies the second of three additional characteristics that users may
define to describe the TGs in the network. The default value of 128 allows a subset of
TGs to be defined as more or less desirable than the rest without defining values for all
TGs.
