Chapter 3 Creating and Editing Screens
3.7.7 Full Screen
Refer to Fig. 3-7-11. Full screen provides maximum view to edit in ScrEdit. Full screen view
will hide all toolbars and docking windows other than the ScrEdit work place itself. Fig. 3-7-11
full screen also shows the reference macro command.
Fig. 3-7-11 Full Screen (Pressing Esc key or left-click the mouse can exit Full screen)
3.7.8 I/O Screen
Refer to Fig. 3-7-12. I/O screen also provides maximum view to edit in ScrEdit just like Full
screen. But the difference is that I/O Screen will show the read and write addresses of the
element and also shows the set macro commands.
Fig. 3-7-12 I/O Screen (Pressing Esc key or left-click the mouse can exit Full screen)
Revision May, 2010 3-73
