Chapter 3 Creating and Editing Screens
3-142 Revision May, 2010
3.8.8.4 Time Display
Property Description of Time Display Element
Display HMI system time. There are several time formats selectable for the user to use.
Text Size
Text Color
The user can set the text size and text color that provided by HMI to
determine the text display on the element. HMI provides 8~64
kinds of default text font for the user to use.
Border Color
Background Color
(Please refer to Table 3.8.2 Property Description of Numeric Display
Element.)
Style
(Please refer to Table 3.8.2 Property Description of Numeric Display
Element.)
Time Format Provide HH:MM:SS, HH:MM two kinds of formats.
X Used to set X coordinate
Y Used to set Y coordinate
Width Used to set the element width
Height Used to set the element height
3.8.8.5 Day-of-week Display
Property Description of Day-of-week Display Element
Display the day (Sunday ~ Monday) of the week. The state default setting of the
Day-of-week display element is set to 7. It indicates that there are 7 states for this
element. The user can define the display text, font and color for each day directly in
the property table.
Text / Text Size
Font / Text Color
The user can set the text, text size, font and text color provided by
Windows® to determine the text display on the element. (Please
refer to Table 3.2.2 Property Description of General Buttons.)
Border Color
Background Color
(Please refer to Table 3.8.2 Property Description of Numeric Display
Element.)
Style
(Please refer to Table 3.8.2 Property Description of Numeric Display
Element.)
X Used to set X coordinate
Y Used to set Y coordinate
Width Used to set the element width
Height Used to set the element height
