Chapter 3 Creating and Editing Screens
3-108
Revision May, 2010
Property Description of Increment / Decrement Buttons
Before Execute
Macro
If this option is set, when the user presses the button, the system
will execute the command of this macro first and then perform the
operation of this button. But, if the state of the button is not
triggered by pressing the button (via macro or external signal), the
command of this macro will not be executed.
After Execute
Macro
If this option is set, when the user presses the button, the system
will perform the operation of this button first and then execute the
command of this macro. But, if the state of the button is not
triggered by pressing the button (via macro or external signal), the
command of this macro will not be executed.
Enable the
confirm window
When this option is set, an Action Confirm dialog box will appear
to prompt the user everytime when the button is pressed.
Invisible Address When this option is set to On, this button element will be invisible.
X
Used to set X coordinate
Y
Used to set Y coordinate
Width
Used to set the element width
Height
Used to set the element height
3.8.2.6 Goto Screen / Previous Page
Property Description of Goto Screen / Previous Page Buttons
Select one of the following to switch screens:
1.
Press the Goto button to go the screen specified.
2.
Press the Previous Page button to return to the previous screen.
Text
Text Size
Font
Text Color
The user can set the text, text size, font and text color provided by
Windows® to determine the text display on the element (Please
refer to Table 3-8-2 Property Description of General Buttons.)
Bank (Picture Bank)
Picture Name
(Please refer to Table 3-8-2 Property Description of General
Buttons.)
Transparent Effect
Transparent Color
(Please refer to Table 3-8-2 Property Description of General
Buttons.)
Foreground Color
Style
(Please refer to Table 3-8-2 Property Description of General
Buttons.)
Function
The user can modify the element characteristic directly without
re-create a new element. The elements that their characteristics
can be modified directly by using this option are: Goto button, and
Previous page and Previous view.
