Chapter 3 Creating and Editing Screens
3-144 Revision May, 2010
Property Description of Moving Sign Element
Text
Text Size
Font
Text Color
The user can set the text, text size, font and text color provided by
Windows® to determine the text display on the element (Please
refer to Table 3-8-2 Property Description of General Buttons.)
Border Color
Background Color
(Please refer to Table 3.8.2 Property Description of Numeric Display
Element.)
Style
(Please refer to Table 3.8.2 Property Description of Numeric Display
Element.)
Property Description of Moving Sign Element
Bit It can have two states.
Word It can have 256 states. Data Length
LSB It can have 16 states.
Data Format
It provides BCD, Signed Decimal, Unsigned Decimal and Hex four
kinds of data format to define the read memory content.
Add/Remove
State
It is used to set the state numbers of moving sign element. If the
data length of the value is in Word, 1~256 states can be set. If the
data length of the value is in LSB, 16 states can be set. If the data
length of the value is in Bit, only 2 states can be set.
Left The display progressing direction is from right to the
left.
Right The display progressing direction is from left to the
right.
Top The display progressing direction is from bottom to the
top.
Direction
Bottom The display progressing direction is from top to the
bottom.
Moving Points
It is used to set the movement of the moving sign. The unit is Pixel
and the range is within 1 ~ 50 Pixels.
Interval(ms)
It is used to set the interval time between two movements. The unit
is ms and the range is within 50 ~ 3000 ms.
X Used to set X coordinate
Y Used to set Y coordinate
Width Used to set the element width
Height Used to set the element height
