Chapter 3 Creating and Editing Screens
3-96 Revision May, 2010
Property Description of General Buttons
Edit On/Off Macro
Edit On and Off Macro is available. When pressing the button, the
state of the button will be ON and the commands of ON Macro will
be executed simultaneously. When pressing the button again, the
state of the button will be changed to OFF and the commands of
OFF Macro will be executed simultaneously. However, if the button
is changed via macro or external signal, not by pressing the
button, ON and OFF macro will not be executed at the same time.
For the Macro function, please refer to section 3-1-14 for more
details.
The user can set the text, text size, fon and text color provided by
Windows® to determine the text display on the element. When the
user presses button next to “Font”, the following “Font Detail
Setting” dialog box will display.
Text
Text Size
Font
Text Color
In “Font Detail Setting” dialog box, the user can select Font Name,
Font Size and Ratio of the text and view the text format from the
Preview window in advance. If the multi-language function is used,
the user can see different language tabs and edit different
language font setting in “Font Detail Setting” dialog box. Please
refer to the example figure above.
