Chapter 3 Creating and Editing Screens
Revision May, 2010 3-93
Button Type Macro Read Write Function
Momentary
ON
OFF
V V
After pressing this button, the state of the setting
address (Bit) will be set to ON and execute ON Macro at
the same time. When pressing the button again, the
state of the setting address will be OFF and execute OFF
Macro simultaneously.
Multistate X V V
There are 1~256 user-defined multi-states for setting.
The user can set the execution sequence to the next
state or the previous state.
Set Value X X V
After pressing this button, the “Numeric keypad” dialog
box will pop up on HMI screen for the user to input the
setting value directly. After inputting the setting value
and pressing ENTER key, HMI will transmit the input
value to the setting address.
Set Constant X X V
After pressing this button, HMI will write the specific
value into the setting address.
Increment X V V
After pressing this button, HMI will add up the value
contained within the setting address and the setting
constant value, and store the addition result back into
the setting address.
Decrement X V V
After pressing this button, HMI will subtract the setting
constant value from the value contained within the
setting address, and store the subtraction result back to
the setting address.
Goto Screen X X X
After pressing this button, it will switch to the screen
that the user designated.
Previous Page X X X
After pressing this button, it will go back to the previous
screen. For example, suppose that there are three
screens, screen 1, screen 2 and screen 3. If the user has
switched the screen from screen 1, screen 2 to screen 3
in order, when pressing “previous page” button on
screen 3, HMI will switch to screen 2. When pressing
“previous page” on screen 2 again, HMI will switch to
screen 3.
System
DateTime
O X X
After pressing this button, it will set the system date and
time of HMI (year-month-day, hours:minutes:seconds).
Password
Table Setup
O X X
After pressing this button, the user can set all the
passwords of user security level.
