Chapter 3 Creating and Editing Screens
Sampling History Buffer Status Register (HSSR)
Corresponding Flag
Corresponding
Buffer Area
Bit
Binary Display of
Relative Position (x)
Function
Buffer Area 1
0
0000 0000 0000 000x Sampling History Buffer Status Flag 1
Buffer Area 2
1
0000 0000 0000 00x0 Sampling History Buffer Status Flag 2
Buffer Area 3
2
0000 0000 0000 0x00 Sampling History Buffer Status Flag 3
Buffer Area 4
3
0000 0000 0000 x000 Sampling History Buffer Status Flag 4
Buffer Area 5
4
0000 0000 000x 0000 Sampling History Buffer Status Flag 5
Buffer Area 6
5
0000 0000 00x0 0000 Sampling History Buffer Status Flag 6
Buffer Area 7
6
0000 0000 0x00 0000 Sampling History Buffer Status Flag 7
Buffer Area 8
7
0000 0000 x000 0000 Sampling History Buffer Status Flag 8
Buffer Area 9
8
0000 000x 0000 0000 Sampling History Buffer Status Flag 9
Buffer Area 10
9
0000 00x0 0000 0000 Sampling History Buffer Status Flag 10
Buffer Area 11
10
0000 0x00 0000 0000 Sampling History Buffer Status Flag 11
Buffer Area 12
11
0000 x000 0000 0000 Sampling History Buffer Status Flag 12
12-15
xxxx 0000 0000 0000 Reserved
Sampling History Buffer Status Flag
When sampling the history buffer, the sampling history buffer status flag will be set to
be ON (Bits 0 to 11 is set to ON). After the sampling operation is completed, the
sampling history buffer status flag will be OFF.
Clearing History Buffer Status Register (HCSR)
Corresponding Flag
Corresponding
Buffer Area
Bit
Binary Display of
Relative Position (x)
Function
Buffer Area 1
0
0000 0000 0000 000x Clearing History Buffer Status Flag 1
Buffer Area 2
1
0000 0000 0000 00x0 Clearing History Buffer Status Flag 2
Buffer Area 3
2
0000 0000 0000 0x00 Clearing History Buffer Status Flag 3
Buffer Area 4
3
0000 0000 0000 x000 Clearing History Buffer Status Flag 4
Buffer Area 5
4
0000 0000 000x 0000 Clearing History Buffer Status Flag 5
Buffer Area 6
5
0000 0000 00x0 0000 Clearing History Buffer Status Flag 6
Buffer Area 7
6
0000 0000 0x00 0000 Clearing History Buffer Status Flag 7
Buffer Area 8
7
0000 0000 x000 0000 Clearing History Buffer Status Flag 8
Buffer Area 9
8
0000 000x 0000 0000 Clearing History Buffer Status Flag 9
Buffer Area 10
9
0000 00x0 0000 0000 Clearing History Buffer Status Flag 10
Buffer Area 11
10
0000 0x00 0000 0000 Clearing History Buffer Status Flag 11
Buffer Area 12
11
0000 x000 0000 0000 Clearing History Buffer Status Flag 12
12-15
xxxx 0000 0000 0000 Reserved
