Delta Electronics DELTA DUP-B User Manual
Page 62
Chapter 3 Creating and Editing Screens
Revision May, 2010
3-41
General Control Status Register 2 (GCSR2)
Bit
Binary Display of Relative
Position (x)
Function
0-7 0000
0000
xxxx
xxxx
Multi-language Status Value
8
0000 000x 0000 0000
Printer Status Flag
9
0000 00x0 0000 0000
Printer Form Feed Status Flag
10-15
xxxx xx00 0000 0000
Reserved
Multi-language Status Value
Bits 0 to 7 read the current language that HMI shows from the multi-language status
value.
Printer Status Flag
When this flag is turned ON, it indicates that the printer is printing the current display
or editing screen. When this flag is turned OFF, the printer function is disabled.
Printer Form Feed Status Flag
When this flag is turned ON, it indicates that the printer is retracting the paper and
aligning the paper for the next run automatically. When this flag is turned OFF, the
printer form feed function is disabled.
