Chapter 3 Creating and Editing Screens
3-240 Revision May, 2010
Alarm Setup Dialog Box
Alarm Setting
The calculation method of the size of the alarm frequency table is as
follows:
Bytes b N a Bytes
Size File Actual 2   ) ( ) (
a Alarm Frequency Data
b Alarm Type
Example:
If there are five alarm types, the required capacity for saving alarm data is:
2 Bytes × 5 = 10 Bytes
When Alarm Moving Sign is enabled, if a fault message is detected by HMI,
an alarm moving sign will show and run on the HMI.
Enable Enable the alarm moving sign.
Position
Determine the display position of alarm moving sign.
It can be Top or Bottom.
Left
Alarm message will move from right to left
(Move to left).
Right
Alarm message will move from left to right
(Move to right).
Up
Alarm message will move from bottom to top
(Move to Up).
Direction
Down
Alarm message will move from top to bottom
(Move to Down).
Moving Points
Set the moving points every time for the alarm moving sign.
The unit is Pixel and the range is between 1 ~ 50 points.
Interval (ms)
Set the interval time every time for the alarm moving sign.
The unit is ms and the range is between 50 – 3000 ms.
Alarm Moving
Sign
Background
Color
Set the background color of the alarm moving sign.
