Chapter 3 Creating and Editing Screens
3-148 Revision May, 2010
Property Description of Animated Graphic Element
Read Address
Use the value of Read Address to switch the
state of animated graphic element.
Read Address+1
Use the value of Read Address+1 to be the
horizontal axis position of the animated
graphic element.
Read Address
Read Address+2
Use the value of Read Address+2 to be the
vertical axis position of the animated graphic
element.
Bank (Picture Bank)
Picture Name
(Please refer to Table 3-8-2 Property Description of General
Buttons.)
Transparent Effect
Transparent Color
(Please refer to Table 3-8-2 Property Description of General
Buttons.)
Clear Picture
Use this option to clear previous animated graphic element when
moving the element or changing the state of the element.
Word It can have 256 states.
Data Length
LSB It can have 16 states.
Data Format
It provides BCD, Signed Decimal, Unsigned Decimal and Hex four
kinds of data format to define the read memory content.
Add/Remove State
It is used to set the state numbers of animated graphic. If the data
length of the value is in Word, 1~256 states can be set. If the data
length of the value is in LSB, 16 states can be set. If the data length
of the value is in Bit, only 2 states can be set.
X Used to set X coordinate
Y Used to set Y coordinate
Width Used to set the element width
Height Used to set the element height
Example of Animated Graphic element:
The designated read address = D100. The internal memory value and each state
should be as follows:
State control register D100
X-axis control register D101
Y-axis control register D102
