Chapter 3 Creating and Editing Screens
Revision May, 2010 3-149
3.8.9.3 Dynamic Line
Property Description of Dynamic Line Element
The dynamic line element can be changed and moved depending on the value of the
corresponding contact or register.
The address can be internal memory or the controller address.
(Please refer to Table 3.2.2 Property Description of General
Buttons.)
Read Address
The value of the Read Address can be used
only when Variable Position option is set to
Yes. It is used to represent the left-top
horizontal position (Left) of the element, i.e.
the first X coordinate on the screen (X
1
).
Read Address +1
The value of the Read Address+1 can be used
only when Variable Position option is set to
Yes. It is used to represent the left-top vertical
position (Top) of the element, i.e. the first Y
coordinate on the screen (Y
1
).
Read Address +2
The value of the Read Address+2 can be used
only when Variable Position option is set to
Yes. It is used to represent the right-bottom
horizontal position (Right) of the element, i.e.
the second X coordinate on the screen (X
2
).
Read Address +3
The value of the Read Address+3 can be used
only when Variable Position option is set to
Yes. It is used to represent the right-bottom
vertical position (Bottom) of the element, i.e.
the second Y coordinate on the screen (Y
2
)..
Read Address +4
The value of the Read Address+4 can be used
only when Variable Color option is set to Yes.
It is used to represent the line color. The
range is different depending on selected HMI.
The range for 16 shades of gray model is
within 0 ~ 15, the range for 256 colors model
is within 0 ~ 255 and the range for 65536
colors is within 0 ~ 65536.
Read Address
Read Address +5
The value of the Read Address+5 can be used
only when Blink option is set to Yes. When the
value is higher than 1, the dynamic line
element will blink. If the value is 0, it will not
blink.
