Chapter 3 Creating and Editing Screens
3-146 Revision May, 2010
Property Description of Static Graphic Element
No
When this option is selected, the value of the read
address will be regarded as the state number. It means
that the state number is determined by the value of the
read address. For example, if the value of the read
address $0 is 0, it will switch to 0th state; if the value of
the read address $0 is 5, it will switch to 5th state.
Yes
When this option is selected and the value of the read
address is a non-zero value, the static graphic element
will change automatically. For example, if the value of
the read address $0 is 1 and higher (a non-zero value),
the element will change the picture automatically
according to the change time that the user set. When
the value of the read address $0 is set to 0, the static
graphic element will be back to the initial state and will
not change the picture automatically.
Auto Change
Variation
When this option is selected, the property of the Read
Address will be the condition of changing element
picture. The element will change the picture
automatically according to Read Address+1. For
example, if $0 is set to display the address of the
element and $1 is set to change the element picture,
when the value of the read address $1is 0, the user
needs to use the read address $0 to switch the state of
the static graphic element. At this time, the static
graphic element will not change automatically, like
when “No” option is selected. When $1 is 1 and higher (a
non-zero value), the static graphic element will change
the picture automatically, like when “Yes” option is
selected.
