Property Description of Historical Data Table Elements
Time/Date
Time
Format
Provide HH:MM:SS, HH:MM two kinds of formats.
Date
Format
Provide MM/DD/YY, DD/MM/YY, DD.MM.YY,
YY.MM.DD, YY/MM/DD, MM.DD, MM/DD seven kinds
of formats.
Color
When time or date format is selected, the user can use
this option to designate the display color.
Date
Length
There are 16bits Word and 32bits Double Word two
options.
There are following data format provided:
Data
Format
Word
1. BCD
2. Signed BCD
3. Signed Decimal
4. Unsigned Decimal
5. Hex
6. Binary Double Word
1. BCD
2. Signed BCD
3. Signed Decimal
4. Unsigned Decimal
5. Hex
6. Binary
7. Floating
Data No.
It is used to set the reading Word data when triggering
every time. For example, if the Data Length option in the
History Setup dialog box is set to 3words, there are 0 ~
2 data numbers can be selected in this option.
Please note that if the data format is selected as
“Floating”, and the Data Length option in the History
Setup dialog box is an odd numbers of words, ensure
to set the Data No. as an even number.
Display
Color
It is used to the display data color.
Setting
Integral
Digits
Fractional
Digits
Use this option to determine the digit number of integer
and decimal fraction. The digit number is not a real digit
number value. It is only the display format. The digit
number will be a real decimal number only when the
data format is selected as “Floating”.
X Used to set X coordinate
Y Used to set Y coordinate
Width Used to set the element width
Height Used to set the element height
