Delta Electronics DELTA DUP-B User Manual
Page 402
Chapter 4 Examples
Then, press OK button to complete the Control Block settings.
In the editing area of HMI, create Numeric Entry elements to indicate recipe buffer (RCP0~RCP4),
recipe table (RCP5~RCP19) and recipe write addresses (1@D100~1@D104). In addition, create
three registers, Recipe Number Designation Register (RCPNO), Recipe Write (1@D5=2) Register
and Recipe Read (1@D5=4) Register by using Numeric Entry elements as shown as the figure
below.
Perform Compile operation and download the screen data into HMI.
Revision May, 2010
4-3
