Chapter 3 Creating and Editing Screens
Revision May, 2010 3-143
3.8.8.6 Prestored Message
Property Description of Prestored Message Element
Display the state content of PLC corresponding contact or register directly. The user
can set state number and text for each state.
Read Address
The address can be internal memory or the controller address.
(Please refer to Table 3-8-2 Property Description of General
Buttons.)
Text
Text Size
Font
Text Color
The user can set the text, text size, font and text color provided by
Windows® to determine the text display on the element (Please
refer to Table 3-8-2 Property Description of General Buttons.)
Border Color
Background Color
(Please refer to Table 3.8.2 Property Description of Numeric Display
Element.)
Style
(Please refer to Table 3.8.2 Property Description of Numeric Display
Element.)
Bit It can have two states.
Word It can have 256 states. Data Length
LSB It can have 16 states.
Data Format
It provides BCD, Signed Decimal, Unsigned Decimal and Hex four
kinds of data format to define the read memory content.
Add/Remove
State
It is used to set the state numbers of prestored message element. If
the data length of the value is in Word, 1~256 states can be set. If
the data length of the value is in LSB, 16 states can be set. If the
data length of the value is in Bit, only 2 states can be set.
X Used to set X coordinate
Y Used to set Y coordinate
Width Used to set the element width
Height Used to set the element height
3.8.8.7 Moving Sign
Property Description of Moving Sign Element
Moving sign is a sign that uses movement, lighting, or special display to depict and
display the state content of the corresponding contact or register. The user can
determine the display of the moving sign by the settings of the direction, moving
points, and interval (ms) in the property table.
Read Address
The address can be internal memory or the controller address.
(Please refer to Table 3-8-2 Property Description of General
Buttons.)
