Chapter 3 Creating and Editing Screens
3.14.1.10 Clock Macro
There is only an Clock Macro in a program or a machine. Similar to Screen Cycle Macro,
it can be executed repeatedly for a specified period of preset clock time. The user can
set Clock Macro Delay Time, i.e. the delay time every time between the end and the
restart of Clock Macro in General tab of Configuration dialog box (See Fig. 3-14-4).
The system default setting is 100ms.
Fig. 3-14-4 Clock Macro Delay Time option
Power on the HMI
Execute Clock Macro
Set cycle delay time to 100ms
(This setting can be user-defined)
After Clock Macro is
executed
Power on the HMI
iagain
Power off the HMI
Repeat
3-286 Revision May, 2010
