Chapter 3 Creating and Editing Screens
3-128 Revision May, 2010
3.8.5.3 Pipe(4)
Property Description of Pipe (4) Element
It is used to connect to water pipe element. Pipe (4) element is shown as the figure
below:
Pipe Gauge:
Use this option to set the pipe gauge. The selectable range is from 1 ~ 5. The setting
value 1 represents at least 13 pixels and the setting value 2 represents at least 26
pixels and vise versa.
Style:
Standard Rotation 90 Rotation 180 Rotation 270
X Used to set X coordinate
Y Used to set Y coordinate
3.8.5.4 Pipe(5)
Property Description of Pipe (5) Element
It is used to connect to several pipes. Pipe (5) element is shown as the figure below:
Pipe Gauge:
Use this option to set the pipe gauge. The selectable range is from 1 ~ 5. The setting
value 1 represents at least 13 pixels and the setting value 2 represents at least 26
pixels and vise versa.
Style:
Standard Rotation 90 Rotation 180 Rotation 270
X Used to set X coordinate
Y Used to set Y coordinate
