Chapter 3 Creating and Editing Screens
3-200 Revision May, 2010
3.8.15.6 Text
Property Description of Text Drawing Element
This text graphic element is used to create a text frame, and add and edit the text on
the screen. The user can drag the mouse across work place on the screen until the text
frame is the size that the user wants and release the mouse to finish. Then, add and
edit the text in the text frame. The foreground color is the color of the text frame.
Text
Text Size
Font
Text Color
The user can set the text, text size, font and text color provided
by Windows® to determine the text display on the element.
The user can set the text, text size, font and text color that
provided by Windows® to determine the text display on the
element. When the user press button next to Font, the
following Font Detail Setting dialog box will display.
In Font Detail Setting dialog box, the user can select Font Name,
Font Size and Ratio of the text and view the text format from the
Preview window in advance. If the multi-language function is
used, the user can see different language tabs and edit different
language font setting in Font Detail Setting dialog box. Please
refer to the example figure above.
Foreground Color
It is used to set the text frame color. Please refer to the figure
below. The foreground color of this text graphic element is set to
blue.
Transparent
When this option is selected, the element will display the text
only and there is no color in the element. The Foreground Color
option will be disabled also.
X Used to set X coordinate
Y Used to set Y coordinate
Width Used to set the element width
Height Used to set the element height
