Chapter 3 Creating and Editing Screens
 FILL (Fill the Memory)
Equation
FILL (Var1, Var2, Var3)
Explanation
FILL (Var1, Var2, Var3) means to fill address Var1 with data in address Var2 for a
sequential V3 number of registers.
Remark
 The calculation result can be stored as unsigned or signed WORD.
 If the block length is more than internal memory or max number of PLC register,
there will be an error when compiling.
 Var1 can be internal memory only. Var2 and Var3 can be internal memory or
constant.
Example
Executing FILL command to fill $0, $1, $2, $3, $4 with constant 0 (this is an
operation of unsigned 16-bit data).
 FILLASC (Convert Text to ASCII code)
Equation
FILLASC (Var1, “Var2”)
Explanation
FILLASC (Var1, “Var2”) means to convert text in address V2 to ASCII code and store in
V1.
Remark
 The calculation result can be stored as unsigned WORD.
 The max length is 128 words.
3-330 Revision May, 2010
