Delta Electronics DELTA DUP-B User Manual
Page 218
Chapter 3 Creating and Editing Screens
Revision May, 2010
3-197
Property Description of Circle Drawing Element
An ellipse that its “Transparent” setting in the property
table is set to “Yes”.
Curve Color
It is used to set the line color of the circle graphic element.
Foreground Color It is used to set the display color of the circle graphic element.
Line Size
The unit is Pixel and the range is within 1 ~ 8.
Transparent
When this option is selected, the element will display only with
the border and there is no color in the element. The Foreground
Color option will be disabled also.
