Delta Electronics DELTA DUP-B User Manual
Page 83
Chapter 3 Creating and Editing Screens
3-62
Revision May, 2010
Icon
Function
Description
New Screen Create a new screen
Open Screen Open an old screen
Print current project
About
Screen editor version
Table 3-7-1 Standard Toolbar
Status Bar
Following is the status bar of Screen Editor (Fig. 3-7-1).
Fig. 3-7-1 Status Bar
Text Toolbar
Icon
Function
Description
Font Size
Display and change text size
Font Name
Display and change text font
Align Txt to Left
Align text to left
Text Center Horizontally
The space at the right/left sides of text
will be the same.
Align Text to Right
Align text to right
Download
Interface
Mouse is moving
Element Coordinate
and Size
Function Connecting
HMI Model
CAP LOCK
NUM LOCK
SCROLL LOCK
