Chapter 3 Creating and Editing Screens
3-136 Revision May, 2010
Property Description of Range Indicator Element
X Used to set X coordinate
Y Used to set Y coordinate
Width Used to set the element width
Height Used to set the element height
3.8.7.3 Simple Indicator
Property Description of Simple Indicator Element
For the user’s convenience, simple indicator provides two states (ON/OFF) to let the
user change the XOR color of the base picture quickly.
Read Address
The address can be internal memory or the controller address.
(Please refer to Table 3-8-2 Property Description of General
Buttons.)
Text
Text Size
Font
Text Color
The user can set the text, text size, font and text color provided by
Windows® to determine the text display on the element (Please
refer to Table 3-8-2 Property Description of General Buttons.)
XOR Color Used to set XOR color of base picture.
Redraw
When this function is enabled, this simple indicator element can be
overlapped and placed on the other dynamic elements to read and
display the data of the dynamic element. When this function is
disabled, the data of the dynamic element can not be read and
displayed.
X Used to set X coordinate
Y Used to set Y coordinate
Width Used to set the element width
Height Used to set the element height
