Chapter 3 Creating and Editing Screens
Revision May, 2010 3-99
Property Description of General Buttons
Function
The user can modify the element characteristic directly without
re-create a new element. The elements that their characteristics
can be modified directly by using this option are: Set button, Reset
button, Momentary button and Maintained button these four
kinds of buttons.
Push Time
(second)
Use this option to set the active time of the button. When this
option is set, the button will be active after pressing the button
longer than the setting time. Using this option can avoid
malfunction. The range is within 0 ~ 10 seconds.
User Security Level
Use this option to set the user priority for pressing this element.
Only the priority that is equal to or higher than the current setting
can use this element.
Set Low Security
Use this option to force the current priority to be the lowest after
the button is pressed. This can prevent the misoperation made by
the user (operator).
InterLock Address
InterLock Level
When InterLock Address is set to be ON or OFF (this is determined
by the property of “InterLock Level”), this button can be enabled.
Before Execute
Macro
If this option is set, when the user presses the button, the system
will execute the command of this macro first and then perform the
operation of this button. But, if the state of the button is not
triggered by pressing the button (via macro or external signal), the
command of this macro will not be executed.
After Execute
Macro
If this option is set, when the user presses the button, the system
will perform the operation of this button first and then execute the
command of this macro. But, if the state of the button is not
triggered by pressing the button (via macro or external signal), the
command of this macro will not be executed.
Enable the
confirm window
When this option is set, an Action Confirm dialog box will appear
to prompt the user everytime when the the button is pressed.
Invisible Address When this option is set to On, this button element will be invisible.
X Used to set X coordinate
Y Used to set Y coordinate
Width Used to set the element width
Height Used to set the element height
