Chapter 3 Creating and Editing Screens
 Record and Output Window
The Record and Output Window displays all the editing actions and output message when
compile function is enabled (Fig. 3-2-11). When HMI program is compiled, the system will
detect the program automatically. Once error occurs, the error messages will be displayed
in Output Window. To get to the error element window, click on the error message.
Fig. 3-2-11 Record and Output window
 Work Place
Following is an editing example display (Fig. 3-2-12).
Editing Area
Fig. 3-2-12 Work Place of Screen Editor
Revision May, 2010 3-15
