Editing Devices
5-139
All specifications subject to change without notification. All rights reserved. Copyright © 2008 NetStreams
Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496
3600 W. Parmer Lane, Suite 100; Austin, TX 7872
2.
After adjusting information on the Info page, select Apply.
3.
Select the Audio tab.
Audio information for the IP speaker displays in the right side of the window (see Figure 5-119).
Figure 5-119
IP Speaker Audio tab
Table 5-97
IP Speaker Info Tab
Tab
Selection Description
Info
Current IP Address
The current IP address of the IP speaker.
Current Subnet Mask
The current subnet mask of the IP speaker.
Device Type
The type of DigiLinX device that this is.
Model Number
The NetStreams StreamNet card model number.
Firmware Version
What firmware version is currently running on the StreamNet
card.
Device Name
Descriptive name the installer assigned to the device when
creating the project.
Override
Changes the default device name. Keep unchecked in most
instances.
Serial Number
Editable field where a source serial number can be entered.
Device Comments
Indicate where the device is installed so that if you need to
return to the installation for service or upgrading devices, you
can have access to this information in the project file.
Room Name
The name of the room where the TouchLinX resides.
Stream Name
The name of the stream routed through the IP speaker.
Speaker Model
The model name of the speaker.
Show Advanced Options
Normally used for advanced configurations. Typically, the
installer will not use this screen.
