Editing Devices
5-125
All specifications subject to change without notification. All rights reserved. Copyright © 2008 NetStreams
Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496
3600 W. Parmer Lane, Suite 100; Austin, TX 78727 / www.netstreams.com.
6. Enter the zone names in the Name field.
Table 5-87 provides information on the fields available for editing the Labels tab.
7. Enter the type of wiring for the zone in the Type field. You can choose from:
ˆ EOL - End of Line Transistor
ˆ NC - Normally Closed
ˆ NO - Normally Open
8. After adjusting information, select Apply.
NOTE: For information on the Input Sensor tab, see Input Sensor Tab on page 5-85.
DoorLinX
Adjust the settings for a DoorLinX connected to the system.
1. Click on the DoorLinX you want to edit in the project.
The Info tab for the DoorLinX displays in the right side of the window (see Figure 5-108). The fields on the
Info tab are described in Table 5-90.
Table 5-89
Labels Tab
Tab Selection Description
Labels Zones Up to 16 zones of security can be defined for the Secant.
Type Refers to how the zone is wired. You can choose from:
 EOL - End of Line Transistor
 NC - Normally Closed
 NO - Normally Open
