Yield Monitor 2000
Acre Counting
Ag Leader Technology
June 1997
4-25
If you incorrectly set the swath for a load, it is easier to adjust the acre
calibration number by a percentage than to adjust actual acres.
Use the following equation to calculate the acre calibration number when the
incorrect number of rows has been set.
Correct #Rows / Incorrect #Rows x 100 = Acre Calibration
Example: If # rows were set on six instead of eight rows, you would set the
acre calibration number to 133 percent because 8/6 x 100 is 133.
Adjusting Field
Acres If you know the exact field acres, adjust the monitor field acres to the
correct value after you finish harvesting the field. Follow these steps to
adjust the field acres:
Step Action
1 Display the field on the top line by itself.
2 Press the AREA key to display acres.
3 Use the bottom right UP or DOWN ARROW keys to set the field
acres to the correct value.
Notes:
•
The monitor proportionally adjusts all the load acres.
•
Usually, the monitor slightly over counts acres because the
combine head is not raised and lowered fast enough on the ends.
* * *
