APPENDIX
C
Manual No. 016-3001-003 231
Appendix C
Calculating the
Calibration Values
Speed Cal
Raven Industries recommends the following values for the initial speed cal:
These values are usually a good starting point and will generally yield adequate results; however, the speed cal
should still be refined for each vehicle.
Using the Calibration Assistance
1. Make sure any section switches are turned OFF before powering the field computer on.
2. Touch within the Product Control area on the main screen.
3. Touch within the Miscellaneous Settings area on the CAN Controller Status screen. The Miscellaneous
Settings screen will display.
Sensor Type English Metric
External Raven GPS
Receiver
785 199
Raven Radar 598 152
Wheel Magnets 1000 254
Speedometer Drive Speed
Sensor
612 155
